SANDANE 2

• PAR 54 IP

• Light Source: 54 x 6W RGBW LED
• LED life expectancy: 20000 hours

• Advanced optical system
• Beam Angle:19°, 23°,30°, 40°, 58°
• Field Angle:37°, 45°,59°, 74°, 100°
• Luminous Flux：10000lm (45°）
• Order Lens Options: D15, D25, D30, D45, D60

• 4-buttons touch panel
• Display: OLED display
• Upgrade the firmware via DMX link
• Protocols: DMX512, RDM, Master/Slave
• DMX Protocol modes: 5
• Channel Modes: 10,8,6,5,4
• Dimmer resolution: 16 bit

• Input voltage range: 100-240V~ 50/60Hz
• Power consumption: 230W
• Power In/Out：Waterproof Power connector In/Out
• Data in/out: 3-pin or 5-pin waterproof XLR

Fixture Specification

• Fixture Dimension：
  • Width: 272 mm (10.7")
  • Depth: 128 mm (5.0")
  • Height: 300 mm (11.8")
  • Weight: 5.5 kg (12 lbs)
• Flight Case Dimension：
  • Height: 550 mm (21.7")
  • Width: 1135 mm (44.7")
  • Depth: 615 mm (24.2")
  • Weight: 111.5 kg (245.8 lbs) (Ten-pack Loader Case)

• Maximum ambient temperature: 40°C
• Minimum operating temperature: -10°C
• Maximum surface temperature: 65°C

• CE compliant

• Available in horizontally or vertically mounting way
• Multi projection angle operation
• Equip with three lockholes with bracket
• 1x Flodable integrated clamp fits for 50mm truss
• Safety rope hanging

• Digital User Manual
• Power Cable
• 1x Flodable integrated clamp fits for 50mm truss

• Flight Case：3205096012 (Ten-pack Loader Case)
• Signal Line：3-pin or 5-pin waterproof signal line
• Anti-glare shield：
  • Half size anti-glare shield：63582245 (black)
  • Full size anti-glare shield：63582244 (black)
• Barndoor：
  • INDOORS BARNDOOR: 63582499(black)
  • OUTDOORS BARNDOOR: 63582720(black)
• Safety cable: 2060000200(SW-02)
